Architect & Contractor Corner

Specification,
without friction.

Everything your practice needs to specify our systems with confidence - data sheets, substrate guidance and hands-on support from first sketch to snagging.

01

Technical Data Sheets

Composition, build-up, coverage, cure times and slip/abrasion performance for every system we install.

02

Substrate Prep Guides

Board, screed, existing tile and timber - tolerances, priming and movement detailing before we arrive on site.

03

Maintenance & Care

Simple aftercare schedules that keep mineral surfaces beautiful for decades - issued with every handover.

04

Specification Assistance

Clause-level wording for your specification, whether it is written in NBS or bespoke - from the contractor who will install it - plus samples and mock-ups for design sign-off.

Working drawings on your desk?

Send us the package and our technical team will come back with system recommendations, budget guidance and lead times.

Build-ups

What sits under the finish.

The substrate build-ups we work to, from the manufacturers' guidance. A microcement finish is about 3 mm in every case and everything below it is what makes the 3 mm last. The lime range, coat by coat, is in the second row.

Walls · dry areas

Hallways, living rooms, bedrooms, feature walls

  1. 01 · Timber battens at 400 or 600 mm centres, noggins behind every board joint
  2. 02 · One or two layers of 12.5 mm plasterboard, all joints scrimmed
  3. 03 · 2-3 mm plaster skim, left rough rather than trowelled smooth, dried fully
  4. 04 · Primer for the substrate, then the 3 mm microcement system: base coats with mesh, top coats, sealer

Walls · wet areas

Bathrooms, wet rooms, utility rooms

  1. 01 · Timber battens as above, then 18 mm marine ply or OSB, or 12 mm cement board
  2. 02 · 12 mm cement board glued and screwed, cross-laid with staggered joints
  3. 03 · Tanking membrane with taped corners and penetrations, tested
  4. 04 · The 3 mm mesh-reinforced microcement system with a two-part wet-area sealer, two coats

Floors · timber joists

Suspended floors in houses and flats

  1. 01 · 18 or 22 mm tongue-and-groove chipboard on the joists
  2. 02 · 12 mm cement board glued and screwed, cross-laid
  3. 03 · Primer, then the 3 mm mesh floor system; double mesh where extra crack resistance is wanted
  4. 04 · Two coats of two-part sealer; protected under breathable board until hard

Floors · screed

Ground floors and slabs

  1. 01 · Sand and cement or liquid screed, minimum C30, surface regularity SR1, laid in bays with movement joints
  2. 02 · Dried naturally, then moisture readings taken by instrument and recorded
  3. 03 · Ground to remove laitance, vacuumed, epoxy primer blinded with sand
  4. 04 · The 3 mm mesh floor system, every substrate joint carried through to the surface

Underfloor heating · wet, in screed

The pairing we build most

  1. 01 · Insulation and damp-proof membrane, the heating pipes, then 50-60 mm liquid or 60-70 mm sand and cement screed, C30 and SR1
  2. 02 · Dried naturally with the heating off
  3. 03 · Commissioning cycle over two weeks: flow temperature up to design maximum and back down, moisture content confirmed
  4. 04 · The 3 mm mesh floor system with the heating off; ramped back up gradually after full cure

Underfloor heating · electric mat

On a timber floor

  1. 01 · Chipboard deck primed with epoxy and scattered with coarse quartz while wet; loose grains vacuumed off once dry
  2. 02 · Electric mat fitted, then a 160 gsm render mesh glued down over it
  3. 03 · At least 10 mm of fibre-reinforced cementitious levelling compound, dried naturally, then the two-week commissioning cycle
  4. 04 · The 3 mm mesh floor system, double mesh optional

The finish, by the sheet

  • Top coats · 0.4-0.5 mm a layer, two-part resin and cement hybrid, rated waterproof
  • Compressive strength · up to 50 N/mm² at 28 days
  • Adhesion to concrete · above 2 N/mm²
  • Abrasion resistance · tested to EN 13892
  • Application · 5-25°C, one hour of working time once mixed

Curves and pool details

  • Curved seating, spa benches and pool ceilings formed on timber or metal track with tile backer board, in layers where the curve is tight
  • 6 mm render skim with a 160 gsm mesh embedded in the middle, dried fully
  • The 3 mm mesh-reinforced system over it with the base coat chosen for the application

Rules that do not move

  • Moisture is measured by instrument, never assumed from the calendar
  • Every movement joint in the substrate is carried through to the surface
  • Heated screeds are commissioned over two weeks before the finish goes on
  • Wet areas are tanked under the finish; the finish is the second line of defence
  • High-traffic and wet surfaces get two coats of sealer

The lime range · coat by coat

  • Venetian plaster, fine grain · 3 coats, about 0.85 kg/m², 0.8-1.2 mm; interior walls
  • Marmorino, medium grain · 3 coats, about 2 kg/m², 1.1-1.6 mm; interior and exterior
  • Marmorino, coarse grain · 3 coats, about 2.7 kg/m², 1.2-1.8 mm; interior and exterior
  • Tadelakt · 2-3 coats, about 2 kg/m², 1.9-2 mm; compressed and stone-polished
  • Travertino · 2 coats, about 3.5 kg/m², 1.9-2.2 mm; interior and exterior
  • Intonachino · 2 coats, 2.8-3.7 kg/m² by grain, 1.8-2.3 mm; interior and exterior
  • Mica metallic · 3 coats, about 1 kg/m², 0.9-1.2 mm; interior walls

The lime range · by the sheet

  • Made of · aged slaked lime and selected marble powders, pH 12.5 at 30 days
  • Reaction to fire · Euroclass A1; VOC under 1 g/l
  • Vapour permeability · Sd around 0.04 m
  • Hardness · 5H pencil; scrub resistance 10,000 cycles
  • Drying · touch dry in 3-5 hours, through in 48; protected from water for 72
  • Application · 5-30°C, humidity under 85%; coats one and two never polished
  • Carbonation · surface in hours, full depth in weeks, more than a month outside

What goes on last

  • Dry rooms · Marseille soap or natural wax, 30-50 g/m² after 48 hours, buffed; refreshed every 5-6 years
  • Bathrooms, kitchens, outside · penetrating mineral water-repellent, 2-3 wet-on-wet coats after 72 hours, non-film-forming, vapour-open
  • Tadelakt · olive-oil soap the next day; mineral repellent and wax where specified
  • Running water · pre-sealer and two coats of water-based polyurethane, which closes the surface; we specify Tadelakt or microcement there instead
  • Never · acids, vinegar or abrasive cleaners on any lime surface

Summary of the manufacturers' substrate guidance and data sheets, for design-stage conversations. The current sheets for the specified products govern on site. Our guide to what each layer is for explains the system coat by coat.

Technical FAQ

The questions every spec meeting asks.

Short answers here; detailed guidance lives in the data sheets and our technical team is a phone call away for anything project-specific.

Which substrates can you apply over?
Cement board, plasterboard, sand-cement screed, anhydrite screed (prepared), existing tile, MDF and blockwork - each with its own priming and reinforcement detail. Timber and anhydrite need particular attention to movement and laitance; our prep guide covers tolerances and we assess every substrate at survey before confirming the build-up.
How long does a typical installation take?
A microcement bathroom typically runs 5-7 working days including waterproofing, coats and curing between them; a seamless floor around 4-6 days before light foot traffic. Venetian plaster rooms depend on coat count and polish level - we sequence with your other trades and confirm a day-by-day programme in the proposal.
Is microcement really waterproof enough for wet rooms?
Yes - as a system. Waterproofing comes from the waterproofing membrane and sealed build-up working together, not the microcement alone, which is why we seal and pressure-test wet areas before a single finish coat goes on. Correctly built, there are no joints or grout lines for water to find.
How do the finishes wear and what maintenance is needed?
Sealed microcement wipes clean with pH-neutral products and shrugs off daily traffic; high-wear commercial floors are re-sealed on a maintenance cycle. Lime plasters mellow beautifully and can be re-waxed to refresh sheen. Every handover includes a written care schedule for your client.
Can you match a colour from another supplier's range?
Almost always. We mix pigment in-studio and match against RAL, NCS or any physical reference - and we confirm the result on a sample panel in your project's light before application, so colour decisions are made on evidence rather than screen renders.
What are the fire and VOC classifications?
The lime range we install - Venetian plaster, Marmorino, Intonachino, Travertino and Tadelakt - is aged slaked lime and marble powder. On the manufacturer's technical data sheets it is Euroclass A1 (non-combustible, no contribution to fire), under 1 g/l of VOC and vapour-open at an Sd of around 0.04 m. Clay plaster is unfired clay, minerals and pigment with no VOC. Microcement is a resin-modified cementitious system with a polyurethane seal: it is not vapour-open and we quote the reaction-to-fire classification from the manufacturer's data sheet for the specified build-up rather than assume one. Data sheets for every system are available on request and on an escape route the class should always be stated in the specification.
Where do you work?
Residential projects across London, Kent and the Home Counties; commercial fit-outs UK-wide and internationally by arrangement. The studio and sample library are at Fox Court on Gray's Inn Road, Holborn - every project colour is confirmed on a sample panel in your own light before work starts.
